SAE Flanges Manufacturer in India

Blazetech Engineering is a manufacturer and supplier of SAE hydraulic flanges in India, providing reliable flange connection solutions for hydraulic systems, industrial machinery, heavy engineering equipment equipment,and high-pressure piping applications.

Our SAE Flangesequipment,flanges are designed around SAE J518 and corresponding ISO 6162 hydraulic flange systems. They are available in different configurations, pressure classes, sizes flangessizes,and materials to suit demanding industrial requirements.

SAE flange connections are particularly useful for larger tube sizes where conventional tube fittings may require higher installation torque or additional space. The compact bolted design provides a secure connection while also allowing easier assembly, inspection sizes,inspection,and maintenance.

SAE J518 Flanges Manufacturer

As an SAE J518 Flanges Manufacturerinspection,flange manufacturer,, Blazetech Engineering offers hydraulic flange assemblies for applications requiring dependable high-pressure connections.

Our product range includes:

• SAE Split Flanges
•

• SAE Mono / Solid Flanges
•

• SAE Captive Flanges
•

• SAE Butt Weld Flanges
•

• SAE Socket Weld Flanges
•

• SAE Threaded Flanges
•

• SAE Blind Flanges
•

• SAE Blanketing / Blanking Flanges
•

• SAE Weld Nozzle Flanges
•

• SAE T-Block Flanges
•

• SAE O-Ring Face Flanges
•

• SAE Flat Face Flanges
•

• SAE Butt Weld Adapters

The supplied configuration can be selected according to the required tube size, pressure class, connection type flange manufacturer,type,and installation arrangement. The source specifications also identify Code 61 and Code 62 configurations and corresponding hydraulic flange dimensions.

ISO 6162 Hydraulic Flangetype,Flanges Supplier

Blazetech Engineering supplies ISO 6162 Hydraulic FlangesFlangehydraulic flanges for hydraulic and industrial applications where compact, high-strength bolted connections are required.

Our range covers hydraulic flange configurations associated with 3000 PSI and 6000 PSI pressure classes, with customized higher-pressure requirements possible depending on the design and application.

The flange assembly can incorporate an O-ring sealing arrangement, flange halves hydraulic flangeshalves,or a solid body, along with suitable bolts, nuts halves,nuts,and washers. These components work together to provide a dependable connection for hydraulic piping systems.

3000 PSI & 6000 PSI SAE Flanges

We offer SAE hydraulic flange solutions for commonly used pressure classes:

Code 61 – 3000 PSI

Suitable for a wide range of industrial and hydraulic applications where a compact flange connection is required.

Code 62 – 6000 PSI

Designed for higher-pressure hydraulic applications where greater pressure capability is required.

The supplied technical reference specifies working pressure up to 210 bar (3000 PSI) and 420 bar (6000 PSI), with customized 700 bar / 10,000 PSI requirements also listed. Actual allowable pressure should be selected according to the applicable standard, size, material nuts,material,and service conditions.

Stainless Steel SAE Flanges

Blazetech Engineering offers Stainless Steelmaterial,stainless steel SAE Flangesstainless steelflanges for applications requiring improved corrosion resistance and suitable mechanical performance.

Available stainless-steel grades include:

• SS 304
•

• SS 316
•

• SS 316Ti
•

• SS 321
•

• SS 310
•

• SS 347

Carbon steel options can also be supplied for suitable applications. The technical reference identifies both forged and bar-stock body constructions.

SAE Flange Size Range

SAE Hydraulic Flangesflangeshydraulic flanges are available in different nominal sizes to accommodate various hydraulic tube and piping requirements.

The referenced range extends from 3/8 inch (DN10) to 5 inch (DN125), with Code 61 and Code 62 dimensional configurations available across applicable sizes.

Custom sizes and dimensions can also be considered based on customer drawings and technical requirements.

SAE Flange Connection Types

Depending on the piping arrangement, Blazetech Engineering can provide different connection configurations, including:

Butt Weld SAE Flanges

Used where the flange is connected to a tube or pipe through a welded connection. This arrangement is suitable for permanent and robust piping assemblies.

Socket Weld SAE Flanges

Designed for applications where the tube is inserted into the flange socket before welding. This configuration provides a compact connection for suitable hydraulic and industrial systems.

Threaded SAE Flanges

Available with threaded connections such as BSPP, NPT, Metric hydraulic flangesmetric,and JIC, depending on the required configuration.

SAE Flange Components & Accessories

A complete SAE flange assembly can include:

• Flange body
•

• Split flange halves
•

• Welding sleeve
•

• O-ring
•

• Bolts
•

• Nuts
•

• Washers

O-ring materials can be selected according to service requirements. The referenced specifications include Nitrile, Buna 90 Shore metric,Shore,and Viton 85–90 Shore options, while high-tensile Grade 8.8, 10.9 Shore,10.9,and 12.9 bolts 10.9,bolts,as well as stainless-steel bolting bolts,bolting,are listed.

Applications of SAE Hydraulic Flanges

Our SAE Hydraulic Flangesbolting,hydraulic flanges are suitable for a wide range of industrial and hydraulic equipment, including:

• Industrial hydraulic systems
•

• Hydraulic presses
•

• Injection mouldinhydraulic flangesmoldingg machinery
•

• AluminiumoldingAluminumm die-casting machinery
•

• Sintering machinery
•

• Steel mills
•

• Paper processing machinery
•

• Mobile hydraulic equipment
•

• Construction machinery
•

• Agricultural machinery
•

• Forestry equipment
•

• Lifting equipment
•

• Material handling equipment
•

• Heavy engineering machinery

These application areas are also reflected in the supplied technical reference.

Customized SAE Flanges

At Blazetech Engineering, we can manufacture and supply customized SAE flangesAluminum according to customer drawings, dimensions, material specifications, and application requirements.

Customization can include:

• Special dimensions
•

• Customized bore sizes
•

• Special materials
•

• Non-standard pressure requirements
•

• Special connection arrangements
•

• Customized flange configurations
•

• Customer-specific machining requirements

Why Choose Blazetech Engineering?

Blazetech Engineering focuses on supplying dependable flange solutions for hydraulic and industrial applications.

Our key strengths include:

• SAE J518 flange solutions
•

• ISO 6162-compatible configurations
•

• Code 61 and Code 62 options
•

• Carbon steel and stainless-steel grades
•

• Forged and bar-stock options
•

• Multiple connection types
•

• O-ring and bolting accessories
•

• Standard and customized designs
•

• Support for customer drawings and specifications
•

• Applications across hydraulic and heavy engineering industries
